Sun Enterprise[tm]250 Server

E250
Sun E250

Processors | Main Memory | Standard Interfaces | Internal Mass Storage | Power Supplies
Environment | Regulations | Dimensions and Weight | Clearance and Service Access | Rack Mounting

Processors
top

Number: Up to two processor modules

Architecture: 250-,300 or 400MHzUltraSPARC[tm]-II with onboard e-cache
X1190A - 250MHz / 1MB Cache Processor
X1191A - 300MHz / 2MB Cache Processor
X1194A - 400MHz / 2MB Cache Processor

Cache Memory:1-MB external cache per processor with 250-MHz CPU

2-MB external cache per processor with 300- or 400-MHz CPU

Datapath: Buffered 144-bit UPA bus, 128 bits data, 16 bits ECC

UPA operates at 100-MHz with 300- or 400-MHz CPUs

501-4681 - E250 Motherboard
Main Memory
top

Capacities: 16 DIMM slots, four banks of four slots

Accepts 32-, 64-, or 128-MB DIMMs

128 MB to 2 GB total memory capacity
X7001A - 16MB DIMM
X7002A - Sun Microsystems 64MB Memory Kit (2 x 32MB)
X7003A - 128MB Memory Kit (2 x 64MB)
X7004A - 256MB Memory Kit (2 x 128MB)
X7043A - 128MB Memory Kit (2 x 64MB)
X6739A - 64MB PCI Fast Write Cache

Memory Type: 144-pin 5V 60-ns memory modules

Datapath: 576 bits wide, 512 bits data, 64 bits ECC

Up to 600 MB/sec throughput

Standard Interfaces
top

Ethernet: One ethernet/fast ethernet (10BASE-T/100BASE-T) twisted-pair standard connector ( RJ-45)) or one MII for external transceiver connection, autoselect port
X4444A - Quad GigaSwift Ethernet UTP (QGE)
X4445A - Quad GigaSwift PCI-X Ethernet (QGE-X)
X1033A - Sun FastEthernet PCI Adapter (FE/P) 2.0
X1034A - Quad FastEthernet PCI (QFE/P)
X1044A - Gigabit Ethernet PCI (GBE/P) 1.0
X1046A - SunSwitch Gigabit Ethernet Switch
X1141A - Gigabit Ethernet PCI (GBE/P) 2.0
X1150A - Sun GigaSwift Ethernet UTP (Copper)
X1151A - Sun GigaSwift Ethernet MMF (Fiber)
X2069A - Gigabit Ethernet FC-AL/P
X3150A - Sun GigaSwift Ethernet UTP (Copper)
X3151A - Sun GigaSwift Ethernet MMF (Fiber)
X467 - MII to AUI Converter

Keyboard and mouse: One standard keyboard/mouse port ( mini DIN-8)

Parallel: One Centronics compatible, bidirectional, EPP port (DB25)

PCI: Four full-size slots compliant with PCI specification version 2.1:

  • One slot operating at 33- or 66-MHz, 32- or 64-bit data bus width, 3.3 volt
  • Three slots operating at 33 MHz, 32- or 64-bit data bus width, 5 volt

Remote System Controller: One RSC port (The highest level firmware for the Enterprise 250 RSC card is version 1.1.4, but the Enterprise 250 does support all currently released versions of the RSC software)

SCSI: One 40MB/sec, 68-pin,Ultra SCSI (SCSI-3), 2 channels (synchronous)

Serial: Two RS-232D/RS423 serial ports (DB25)
Internal Mass Storage
top

Disks: Up to six 18-GB 3.5 x 1.6 in., 36-GB 3.5 x 1.0 in., 10000 rpm, hot-pluggable Ultra SCSI-3 drives
(4.2-GB and 9.1-GB 7200 also configured)

Disk bays: Six hot-pluggable disk bays
Disk controllers: One 40-MB/sec Ultra SCSI-3 channel
X5242A - 36.4GB 10000 RPM
X5214A - 4.2GB 7200 RPM
X5229A - 9.1GB 7200 RPM
X5234A - 9.1 GB 10000 RPM
X5237A - 18.2 GB 10000 RPM

CD-ROM/DVD-ROM: Internal SunCD 32 (standard)

Internal 10X DVD-ROM drive (standard)
X6168A - 10X DVD-ROM Drive

Floppy: 1.44-MB 3.5-in. floppy drive
X6005A - Manual Eject Triple Density Floppy

Tape: Optional 5.25 x 1.6 in. fast SCSI tape drive, 8-mm, 4-mm DDS-3, DDS-2, MLR3, SLR5
X6107A - 4-8 GB 1/4" SLR Tape Drive
X6213A - 7-14GB 8 mm Tape Drive (Medium Grey Bezel)
X6286A - 12-24GB 4 mm DDS-3 Tape Drive (Medium Grey Bezel)
X6295A - 20-40GB 4 mm DDS-4 Tape Drive (Medium Grey Bezel)

Power Supplies
top

X9683A - Power Supply for E250
Type: One or two N+1 redundant, hot-swap, universal input (1 supply standard)

Output: 360 W

Power Bus: Common, load-sharing

Enviornment
top

AC input: 100 - 240 VAC, 47 - 63 Hz, 2.8 A(max)

Input power: 343 W

Heat Output: 1170 BTU/hr

Temperature*: Operating: 5° C to 35° C (41° F to 95° F)
Nonoperating: -20° C to 60° C (-4° F to 140° F)

Humidity: Operating: 20% to 80% relative humidity, noncondensing
Nonoperating: 5% to 93% relative humidity, noncondensing

Altitude: Operating: 3000 m (10,000 ft.)
Nonoperating: 12,000 m (40,000 ft.)

Acoustic noise: Operating: 6.5 bels
Idling: 6.3 bels

Vibration: Operating: 0.2G peak, 5 - 500 Hz (swept sine)
0.0002 G 2 /H:z, 5 - 500 Hz (random)
vertical axis only (castered configuration), vertical and horizontal axes (foot glide configuration)
Nonoperating: 1G peak, 5 - 500 Hz (swept sine)
0.002 G 2 /Hz, 5 - 500 Hz (random), 3 perpendicular axes

Shock: Operating: 4G peak, 11 milliseconds half-sine pulse
Nonoperating: 15G peak, 11 milliseconds half-sine pulse

Number of cords: 1

Plug Type-U.S.: NEMA 5-15P

Plug type International: IEC 320, 10 A, 250 VAC

* The front and rear doors of the cabinet must be 63% open for adequate air flow.

Regulations :(meets or exceeds the following requirements)
top

Safety: EN60950/IEC950 TUV, UL 1950, CB Scheme IEC 950, C22.2 No. 950 from UL

RFI/EMI: EN55022/CISPR22 Class B, VCCI Class II FCC Part 15 Sub Part B

Immunity: EN50082/IEC-1000-2/IEC-1000-3, IEC-1000-4, IEC-1000-5

X-ray: DHHS 21 Subchapter J, PTB German X-ray Decree

Dimensions and Weights
top

Height : 46.0 cm (18.1 in.) or 51.7 cm (20.4 in.) with caster option
90.8 cm (35.75 in.) shipping

Width: 26.2 cm (10.3 in.)
45.72 cm (18.0 in.) shipping

Depth: 68.8 cm (27.1 in.), power supply handles add 3.1 cm (1.2 in.)
86.36 cm (34.0 in.) shipping

Weight: 53 kg (118 lb.)
58.97 kg (130 lb.) shipping

Power Cord: 2.5 m (8.2 ft.)

Clearance and Service Access
top

Front: 91.4 cm (36 in.)

Rear: 91.4 cm (36 in.)

Right: 91.4 cm (36 in.)

Left: 91.4 cm (36 in.)

Rack mounting
top

X9695A - Rack Mount Kit for E250
Up to four Sun Enterprise 250 servers may be mounted in a 56-in. expansion cabinet. Up to five Enterprise 250 servers may be mounted in a 72-in. expansion cabinet .
